With a trio of different bed options and a trio of cabs, the 2026 Ford F-150 dimensions can be customized to fit the kind of truck you need for life around Fort Smith, AR or Eufaula. Check out the charts below (and don’t forget to check its towing capacity), then find your next pickup in our inventory at Riverside Autoplex of Poteau.
| Interior Dimensions | Regular Cab | SuperCab | SuperCrew |
|---|---|---|---|
| Passenger Capacity | 3 | 5–6 | 5–6 |
| Front Head Room | 40.8 In | 40.8 In | 40.8 In |
| Front Leg Room | 43.9 In | 43.9 In | 43.9 In |
| Front Shoulder Room | 66.7 In | 66.7 In | 66.7 In |
| Front Hip Room | 62.5 In | 62.5 In | 62.5 In |
| Rear Head Room | — | 40.3 In | 40.4 In |
| Rear Leg Room | — | 33.5 In | 43.6 In |
| Rear Shoulder Room | — | 66.1 In | 66.0 In |
| Rear Hip Room | — | 62.6 In | 62.6 In |
| F-150 Bed Size | 5.5 Ft Bed | 6.5 Ft Bed | 8.0 Ft Bed |
|---|---|---|---|
| Length | 67.1 In | 78.9 In | 97.6 In |
| Max Width | 65 In | 65 In | 65 In |
| Between Wheels | 51 In | 51 In | 51 In |
| Side Height | 21 In | 21 In | 21 In |
| Tailgate Width | 60 In | 60 In | 60 In |
| Cargo Volume | 52.8 Cu Ft | 62.3 Cu Ft | 77.4 Cu Ft |
| Available On | Regular Cab | Regular Cab | |
| SuperCab | SuperCab | ||
| SuperCrew | SuperCrew |
| F-150 Exterior Dimensions | Regular Cab | SuperCab | SuperCrew |
|---|---|---|---|
| Wheelbase (6.5 Ft Bed) | 122.8 In | 145.4 In | 145.4 In |
| Wheelbase (8 Ft Bed) | 141.5 In | 157.2 In | 157.2 In |
| Overall Length (6.5 Ft Bed) | 232.0 In | 232.0 In | 231.7 In |
| Overall Length (8 Ft Bed) | 243.8 In | 243.8 In | 243.8 In |
| Body Width | 79.9 In | 79.9 In | 79.9 In |
| Width Mirrors Folded | 83.6 In | 83.6 In | 83.6 In |
| Width With Mirrors | 95.7 In | 95.7 In | 95.7 In |
| Height | 75.4 In | 77.1 In | 77.5 In |
| Front Track | 67.9 In | 67.9 In | 67.9 In |
| Rear Track | 68.3 In | 68.3 In | 68.3 In |
| Front Overhang | 37.4 In | 37.4 In | 37.4 In |
| Rear Overhang | 49.2 In | 49.2 In | 49.2 In |
| Ground Clearance | 8.0 In | 9.0 In | 9.0 In |
| Load Floor Height | 33 In | 36 In | 36 In |
While we think the numbers paint a pretty clear picture about the 2026 Ford F-150 dimensions and specs, if you’re undecided between the Regular Cab, SuperCab, and SuperCrew versions, it’s best to see them for yourself. Contact us today to schedule some time in the cab or drop by the Riverside Autoplex of Poteau showroom for a test drive.
